milling spindle saw blade air cooled high speed cnc spindle motor low speed high torque 3000rpm spindle motor for cncPower：2.2kw Voltage：380V Connect：ER25 Speed：3000RPM Frequency：50Hz
Collect
Modle:GDZ-63L1-3B/2.2kwThe technical requirements 1. This is air cooled spindle. 2.This type spindle has big torque. 3. Frequency is 50HZ. 4. the speed is 3000RPM. 5. It can using connected directly to the power supply. 6. Must notice that the Voltage is 380V. 7.It also can using the VFD to control the spindle , like 0-3000RPM can be control.And it also have 220V , but should using the VFD. 8.The input power is connected to the LN port of the Inverter, and the UVW port of the Inverter is connected to the spindle.
